MCM110SC2P - StarTech 10Mbps 10/100Base-TX Fast Ethernet Media Converter
- Wired
- 100 Mbit/s 2000 m 1310 nm
- 100BASE-TX
- Ethernet LAN (RJ-45) ports: 1 DC-in jack
- Multi-mode SC
Was $204.35 · You save $30.35
Key specifications
See full specs ↓- Maximum data transfer rate
- 100 Mbit/s
- Converter input interface
- 100BASE-FX
- Networking standards
- IEEE 802.1Q, IEEE 802.3u
- Ethernet interface type
- Fast Ethernet
- Ethernet LAN data rates
- 10,100 Mbit/s
- Copper ethernet cabling technology
- 100BASE-TX
Specifications: Specs Icecat. Product content is provided as-is; confirm critical details with us before ordering.
Product details
StarTech.com 10/100 Multi Mode Fiber to Ethernet Media Converter SC 2km with PoE. Maximum data transfer rate: 100 Mbit/s, Converter input interface: 100BASE-FX, Networking standards: IEEE 802.1Q, IEEE 802.3u. Maximum transfer distance: 2000 m, Wavelength: 1310 nm, Fiber mode structure: Multi-mode. LED indicators: Activity, Link, PoE, Power, Housing material: Plastic. Fiber optic connector: SC, Connectivity technology: Wired. Input voltage: 115 V, Output voltage: 12 V, Output current: 0.4 A
Network
| Maximum data transfer rate | 100 Mbit/s |
| Converter input interface | 100BASE-FX |
| Networking standards | IEEE 802.1Q, IEEE 802.3u |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Copper ethernet cabling technology | 100BASE-TX |
| Duplex system | Full, Half |
Performance
| Maximum transfer distance | 2000 m |
| Wavelength | 1310 nm |
| Wavelength-division multiplexing (WDM) | Yes |
| Fiber mode structure | Multi-mode |
| Mean time between failures (MTBF) | 65000 h |
Features
| Internal | No |
| LED indicators | Activity, Link, PoE, Power |
| Housing material | Plastic |
Ports & interfaces
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber optic connector | SC |
| DC-in jack | Yes |
Power
| Input voltage | 115 V |
| Output voltage | 12 V |
| Output current | 0.4 A |
| Power consumption (typical) | 4.8 W |
| Power over Ethernet (PoE) | Yes |
| External power adapter | Yes |
| Power plug type | Type M |
Weight & dimensions
| Width | 75 mm |
| Depth | 95 mm |
| Height | 20 mm |
| Weight | 90 g |
Operational conditions
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Packaging content
| AC adapter included | Yes |
| User guide | Yes |
Packaging data
| Package width | 60 mm |
| Package depth | 172 mm |
| Package height | 143 mm |
| Package weight | 300 g |
Certificates
| Compliance certificates | RoHS |
| Certification | CE, FCC |
Description
Convert and extend a 10/100 Mbps Ethernet connection up to 2 km over Multi Mode SC fiber - with PoE The MCM110SC2P 10/100 Multi Mode Fiber to Ethernet Media Converter supports a maximum fiber cable distance of 2km, ensuring a highly reliable signal for ideal network connectivity and performance. Featuring Power over Ethernet support, the converter draws power from a PoE network, delivering the freedom to use the converter in environments and scenarios where additional standard power options are unavailable. Rather than paying for expensive installations of power wire (at drop points that may have them), running PoE requires only standard network cable (e.g. Cat5e cable), eliminating added cost and hassle. Backed by a StarTech.com 2-year warranty and free lifetime technical support, the 10/100Base to 100Base-FX Multimode Fiber Ethernet Media converter features a durable design to help ensure reliability and long-lasting performance. The StarTech.com Advantage
Condition: Refurbished
Free U.S. ground shipping
Typically 1–2 days handling, 3–7 days in transit.
Purchase orders accepted
Government, enterprise, data center and small business.
Buying 10+ units?
Get volume pricing and availability for MCM110SC2P.
