TP-LINK TL-WR642G 108Mbps Wireless Router

Safe checkout

Secure payments

Fast dispatch

1–2 day handling

Free shipping

U.S. ground

Warranty & RMA

Support after delivery

TP-LINK TL-WR642G 108Mbps Wireless Router

SKU TL-WR642G
Brand TP-LINK
  • Black, White
  • Ethernet LAN (RJ-45) ports: 4
  • Web-based management
Available to order

TL-WR642G isn't on our shelf today — we source it to order. Request a quote and we'll confirm price and lead time within one business day.

Key specifications

See full specs ↓
Modulation
DBPSK, DQPSK, DSSS, OFDM, QPSK
Supports ISDN connection
No
Receiver sensitivity
108M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER 256K: -105dBm@8% PER
Ethernet LAN (RJ-45) ports
4
Web-based management
Yes
Reset button
Yes

Product details

TP-Link TL-WR642G. Modulation: DBPSK, DQPSK, DSSS, OFDM, QPSK. Receiver sensitivity: 108M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER.... Authentication method: 802.1x RADIUS. Supported network protocols: CP/IP, PPPoE, ICMP, NAT. Product colour: Black, White

Wireless LAN features

ModulationDBPSK, DQPSK, DSSS, OFDM, QPSK

Network

Supports ISDN connectionNo
Receiver sensitivity108M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER 256K: -105dBm@8% PER

Ports & interfaces

Ethernet LAN (RJ-45) ports4

Management features

Web-based managementYes
Reset buttonYes

Security

Authentication method802.1x RADIUS
FilteringYes
MAC address filteringYes

Protocols

DHCP clientYes
DHCP serverYes
Universal Plug and Play (UPnP)Yes
Supported network protocolsCP/IP, PPPoE, ICMP, NAT

Design

Product colourBlack, White
Indication lightYes
LED indicatorsYes

Antenna

Antenna connector typeRP-SMA
Antenna gain level (max)3 dBi

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 95%

Other features

Dimensions (WxDxH)174 x 111 x 30 mm
Indoor range800m
Supported data transfer rates108/54/48/36/24/18/12/9/6/11/5.5/3/2/1 Mbps
Output power description9VAC / 0.8A
Outdoor range200m
Maximum data transfer rate0.108 Gbit/s
Frequency range2.4-2.4835GHz
xDSL connectionNo

Description

The TL-WR642G 108Mbps Wireless Router integrates firewall, NAT-router and Wireless AP. The design is dedicated to Small Office/Home Office (SOHO) Wireless network solution. The TL-WR642G 108Mbps Wireless Router will allow you to connect your network wirelessly better than ever, sharing Internet Access, files and fun, easily and securely. With the most attentive wireless security, the TL-WR642G 108Mbps Wireless Router provides multiple protection measures. It can be set to turn off wireless network name (SSID) broadcast so that only stations that have the SSID can be connected. The router provides wireless LAN 64/128/152-bit WEP encryption security, and WPA/WPA2 and WPA-PSK/WPA2-PSK authentication and TKIP/AES encryption security. It also supports VPN pass-through for sensitive data secure transmission. The TL-WR642G 108Mbps Wireless Router complies with the IEEE 802.11g/b standards and adopts 108M Super G™ WLAN transmission technology so that data rate is up to 108Mbps. It adopts 2x to 3x eXtended Range™ WLAN transmission technology so that transmission distance is 2-3 times that of traditional 11g/b solutions, up to 855.36m tested in China. Transmission range is extended to 4-9 times. It is compatible with all IEEE 802.11g and IEEE 802.11b products. The TL-WR642G 108Mbps Wireless Router provides flexible access control so that parents or network administrators can establish restricted access policies for children or staff. It has built-in NAT and DHCP server supporting static IP address distributing. It also supports Virtual Server and DMZ host for Port Triggering needs, as well as remote management and log so that network administrators can manage and monitor the network on real time. The TL-WR642G 108Mbps Wireless Router is easy-to-manage. Quick Setup Wizard is supported and friendly help messages are provided for every step. So you can configure it quickly and share Internet access, files and fun.
