TP-LINK EAP235-WALL Omada 1200Mbs 2.4/5GHz 1x PoE+ 1000BT Access Point

TP-LINK EAP235-WALL Omada 1200Mbs 2.4/5GHz 1x PoE+ 1000BT Access Point

SKU EAP235-WALL
TP-LINKShop all TP-LINK parts (491) ›
  • Elegant Appearance: 15 mm ultra slimmest and conspicuous design blends into hotel rooms, hospital, offices, dormitories and any other environments
  • Cloud management and Omada app supported for ultra-convenience and easy management
  • Enterprise class Wi-Fi security helps to decrease network security threats
  • Secure guest network along with Facebook Wi-Fi/SMS authentication options and wireless security technology
In Stock
$154.00

Was $180.82 · You save $26.82

Free U.S. ground shippingArrives Wed, Nov 25 – Wed, Dec 2Faster options available at checkout

Key specifications

See full specs ↓
2.4 GHz
Yes
5 GHz
Yes
6 GHz
No
Maximum data transfer rate
1167 Mbit/s
Maximum data transfer rate (2.4 GHz)
300 Mbit/s
Maximum data transfer rate (5 GHz)
867 Mbit/s

Product details

TP-Link Omada AC1200 Wireless MU-MIMO Gigabit Wall Plate Access Point. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1167 Mbit/s. Security algorithms: 64-bit WEP, 128-bit WEP, 152-bit WEP, 802.1x RADIUS, HTTPS, SNMP, SNMPv3, SSH, WPA,.... Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White

Specifications

2.4 GHz
Yes
5 GHz
Yes
6 GHz
No
Maximum data transfer rate
1167 Mbit/s
Maximum data transfer rate (2.4 GHz)
300 Mbit/s
Maximum data transfer rate (5 GHz)
867 Mbit/s
Ethernet LAN data rates
10,100,1000 Mbit/s
Frequency band
2.4 - 5 GHz
Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Cabling technology
10/100/1000Base-T(X)
Automatic channel selection
Yes
Automatic channel scanning
Yes
MIMO
Yes
MIMO type
Multi User MIMO
Wi-Fi Multimedia (WMM)/(WME)
Yes
VLAN support
Yes
Virtual LAN features
Port-based VLAN, VLAN mapping
Rate limiting
Yes
Wireless isolation
Yes
Band steering
Yes
Quality of Service (QoS) support
Yes
BeamForming
Yes
Transmitting power (CE)
20 - 23 dBm
Transmitting power (FCC)
21 dBm
Security algorithms
64-bit WEP, 128-bit WEP, 152-bit WEP, 802.1x RADIUS, HTTPS, SNMP, SNMPv3, SSH, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA2-Enterprise, WPA2-PSK
MAC address filtering
Yes
Service Set Identifier (SSID) features
Multiple SSIDs
Number of SSID supported
16
Remote Authentication Dial-In User Service (RADIUS)
Yes
Access Control List (ACL)
Yes
Universal Plug and Play (UPnP)
Yes
Web-based management
Yes
Syslog
Yes
Ethernet LAN (RJ-45) ports
4
WAN connection
Ethernet (RJ-45)
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) type supported
Active PoE, Passive PoE
Power consumption (typical)
24.4 W
Placement
Wall
Product colour
White
Cable lock slot
Yes
Reset button
Yes
LED indicators
LAN, Power, Status, WAN, WLAN
Antenna type
Internal
Antenna features
Integrated antenna
Antennas quantity
2
Antenna gain level (max)
4 dBi
Compatible operating systems
Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10
Compliance certificates
CE, Federal Communications Commission (FCC), RoHS
Width
143 mm
Depth
86 mm
Height
20 mm
Package width
117 mm
Package depth
184 mm
Package height
33 mm
Package weight
300 g
Package type
Box
Quantity per pack
1 pc(s)
Mounting kit
Yes
Quick start guide
Yes
Operating relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-40 - 70 °C
Storage relative humidity (H-H)
5 - 90%
Sustainability compliance
Yes
Harmonized System (HS) code
85176990

Description

Dedicated Complete, Private Wi-Fi Network in Each Room An EAP in each room allows guests to enjoy their own private Wi-Fi network that’s fast, delivering a strong signal, and providing corner to corner coverage. MU-MIMO + Dual-Band: Connect Faster and More 802.11ac wave 2 MU-MIMO technology enables multiple users to access the Internet simultaneously, which largely boosts up your network speed of up to 1,200 Mbps. Capable of transmitting in both 2.4 GHz and 5 GHz wireless band, it provides greater compatibility to connect varieties of devices. Absolute Thinnest, Inconspicuous Design The thinnest wall plate AP available—only 15 mm—featuring a sleek, minimalist appearance. Designed to blend in with the décor of hotel rooms, hospitals, offices and school dormitories, to deliver powerful Wi-Fi without clashing with the room. Effortless Deployment with PoE Powered With 802.3af/802.3at Power over Ethernet supported there’s no need to install additional wiring in the building. Simply plug in existing Ethernet cables and you’re ready to go. Quick, Simplified Installation EAP235-Wall is easy to install, so extra cost, time, or professional knowledge are completely unnecessary. Full Gigabit Ports to Bridge Network Equipped with four Gigabit data ports (1 uplink + 3 downlink), one downlink port offering PoE pass-through, to connect multiple devices to your gigabit network. Wired devices like VoIP phones can be powered with no need for extra electrical cables. Cloud Centralized Management Anytime, Anywhere Omada Cloud Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself. Easy Management with the Omada App Follow configuration instructions on the Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.
