Supermicro MBD-X9SCA Socket LGA1155 Intel C204 ATX Motherboard
Shop all Supermicro parts (3,390) ›- Socket LGA1155 for Intel Xeon E3-1200 series processors
- Intel C204 Chipset
- ATX Form Factor
- Supports ECC DDR3 Memory
- Multiple PCIe slots for expansion
- Integrated Graphics (optional, depending on CPU)
- SATA 6Gb/s ports for storage
- Server/Workstation focused features
MBD-X9SCA isn't on our shelf today — we source it to order. Request a quote and we'll confirm price and lead time within one business day.
Key specifications
See full specs ↓- Motherboard Type
- ATX
- Socket
- LGA1155
- Chipset
- Intel C204
- CPU Support
- Intel Xeon E3-1200 series, Core i3, Pentium
- Memory Type
- DDR3 ECC Unbuffered DIMM
- Memory Slots
- 4 x DIMM
Product details
The Supermicro MBD-X9SCA is an ATX form factor motherboard designed for Intel Xeon E3-1200 series processors with an LGA1155 socket. It features the Intel C204 chipset and supports ECC memory, making it suitable for entry-level servers and workstations.
Specifications
- Motherboard Type
- ATX
- Socket
- LGA1155
- Chipset
- Intel C204
- CPU Support
- Intel Xeon E3-1200 series, Core i3, Pentium
- Memory Type
- DDR3 ECC Unbuffered DIMM
- Memory Slots
- 4 x DIMM
- Expansion Slots
- 2 x PCIe 3.0 x16, 1 x PCIe 2.0 x4, 1 x PCI
- Storage Ports
- 2 x SATA 3.0 (6Gb/s), 4 x SATA 2.0 (3Gb/s)
- Integrated Graphics
- Varies by CPU (e.g., Intel HD Graphics P4000)
Description
The Supermicro MBD-X9SCA is a robust ATX motherboard engineered for reliability and performance in server and workstation environments. It utilizes the Intel C204 chipset and supports processors from the Intel Xeon E3-1200 family, as well as compatible Core i3 and Pentium processors, all utilizing the LGA1155 socket. This combination provides a solid foundation for applications requiring moderate processing power and stability. A key feature of the MBD-X9SCA is its support for ECC (Error-Correcting Code) DDR3 memory. ECC memory is crucial in server and workstation applications as it can detect and correct common types of internal data corruption, thereby enhancing system stability and data integrity. The motherboard typically offers four DIMM slots, allowing for a significant amount of memory to be installed, further boosting performance for memory-intensive tasks. Expansion capabilities are well-addressed with multiple PCI Express slots, including PCIe 3.0 x16 slots for high-bandwidth graphics cards or other peripherals, and additional PCIe and PCI slots for broader compatibility. Storage connectivity is provided through SATA 6Gb/s and 3Gb/s ports, supporting a variety of hard drives and SSDs. The integrated graphics, dependent on the installed CPU, can eliminate the need for a separate graphics card in basic display scenarios, making it a cost-effective solution for certain deployments.
