StarTech ET90110SC2 1-Fiber Optic + 1-RJ-45 FE MMF Media Converter
- Wired
- 200 Mbit/s 2000 m 1310 nm
- Black
Key specifications
See full specs ↓- Maximum data transfer rate
- 200 Mbit/s
- Networking standards
- IEEE 802.3, IEEE 802.3u
- Auto MDI/MDI-X
- Yes
- Duplex system
- Full, Half
- Maximum transfer distance
- 2000 m
- Wavelength
- 1310 nm
Product details
StarTech.com 10/100 Mbps Multi Mode Fiber Media Converter SC 2 km. Maximum data transfer rate: 200 Mbit/s, Networking standards: IEEE 802.3, IEEE 802.3u, Duplex system: Full, Half. Maximum transfer distance: 2000 m, Wavelength: 1310 nm, Fiber mode structure: Multi-mode. Product colour: Black, Housing material: Steel. Fiber optic connector: SC, Connectivity technology: Wired. Input voltage: 100 - 240 V, Output voltage: 12 V, Output current: 1.6 A
Specifications
- Maximum data transfer rate
- 200 Mbit/s
- Networking standards
- IEEE 802.3, IEEE 802.3u
- Auto MDI/MDI-X
- Yes
- Duplex system
- Full, Half
- Maximum transfer distance
- 2000 m
- Wavelength
- 1310 nm
- Wavelength-division multiplexing (WDM)
- No
- Fiber mode structure
- Multi-mode
- Internal
- No
- Product colour
- Black
- Housing material
- Steel
- Connectivity technology
- Wired
- Ethernet LAN (RJ-45) ports
- 1
- Fiber ports quantity
- 1
- Fiber optic connector
- SC
- Input voltage
- 100 - 240 V
- Output voltage
- 12 V
- Output current
- 1.6 A
- Power over Ethernet (PoE)
- No
- Power plug type
- Type M
- Width
- 87 mm
- Depth
- 153 mm
- Height
- 24 mm
- AC adapter included
- Yes
- Manual
- Yes
- Package width
- 190 mm
- Package depth
- 233 mm
- Package height
- 77 mm
- Package weight
- 779 g
- Compliance certificates
- RoHS
- Certification
- CE, FCC
- Harmonized System (HS) code
- 85176990
- Dimensions (WxDxH)
- 95 x 160 x 20 mm
- Full duplex
- Yes
Description
Convert and extend a 10/100 Mbps Ethernet connection up to 1.2 miles/2km over Multi Mode SC fiber The ET90110SC2 10/100 Mbps Multimode Fiber Media Converter SC (2 km) lets you extend a Fast Ethernet network (10/100Mbps) over multimode fiber, at distances up to 2 km (1.2 miles). A cost-effective solution for connecting a 10/100 Mbps Ethernet (10/100Base-T) network to remote network segments over a 100Base-FX fiber backbone, the media converter is designed to offer a durable and convenient Ethernet-to-fiber solution, featuring an all-steel chassis, and a simple plug-and-play installation with minimal configuration required. For added versatility, this fiber media converter supports standalone operation, or installation into the 20 Slot, 2U Rackmount Chassis (ETCHS2U). Backed by a StarTech.com 2-year warranty and free lifetime technical support. The StarTech.com Advantage - Link loss forwarding, remote status monitoring help ensure maximum up-time - Provides Ethernet to Fiber conversion as a standalone device, or can be installed into the ETCHS2U 20 slot chassis for added versatility - Rugged steel casing for durability in harsh environments
Condition: Refurbished
Free U.S. ground shipping
Typically 1–2 days handling, 3–7 days in transit.
Purchase orders accepted
Government, enterprise, data center and small business.
Buying 10+ units?
Get volume pricing and availability for ET90110SC2.
