DS51072 - StarTech 5-Port 10/100/1000Base-T Unmanaged Fast Ethernet Switch
- Basic switching RJ-45 Ethernet ports quantity: 5
- 100BASE-TX, 10BASE-T
- AC/DC
DS51072 isn't on our shelf today — we source it to order. Request a quote and we'll confirm price and lead time within one business day.
Key specifications
See full specs ↓- Basic switching RJ-45 Ethernet ports quantity
- 5
- Power connector
- DC-in jack
- Networking standards
- IEEE 802.3, IEEE 802.3u
- 10G support
- No
- Copper ethernet cabling technology
- 100BASE-TX, 10BASE-T
- Full duplex
- Yes
Product details
StarTech.com 5 Port Fast Ethernet Switch - 10/100 Desktop Wall Mount Network Switch. Basic switching RJ-45 Ethernet ports quantity: 5. Full duplex, Networking standards: IEEE 802.3, IEEE 802.3u. DC input voltage: 9 V. Power connector: DC-in jack
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Power connector | DC-in jack |
Network
| Networking standards | IEEE 802.3, IEEE 802.3u |
| 10G support | No |
| Copper ethernet cabling technology | 100BASE-TX, 10BASE-T |
| Full duplex | Yes |
| Flow control support | Yes |
| Auto MDI/MDI-X | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
Data transmission
| Supported data transfer rates | 10/100 Mbps |
| Store-and-forward | Yes |
| Maximum data transfer rate | 0.1 Gbit/s |
Security
| MAC address filtering | Yes |
Protocols
| Supported network protocols | CSMA/CD |
Design
| Rack mounting | No |
| Product colour | Black |
| Housing material | Plastic |
| LED indicators | Link, Power |
Power
| Power source | AC/DC |
| Number of power supply units | 1 |
| AC input voltage | 110 - 240 V |
| DC input voltage | 9 V |
Other features
| Connectivity technology | Wired |
| Networking features | Fast Ethernet |
| Power LED | Yes |
| Ethernet LAN | Yes |
| Ethernet interface type | Fast Ethernet |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Relative humidity | 10 - 90% |
Weight & dimensions
| Width | 90 mm |
| Depth | 140 mm |
| Height | 25 mm |
| Weight | 122 g |
Packaging content
| Manual | Yes |
Packaging data
| Package width | 168 mm |
| Package depth | 208 mm |
| Package height | 65 mm |
| Package weight | 331 g |
Certificates
| Certification | CE, FCC, RoHS |
Description
Connect and network up to 5 Ethernet devices through a single 10/100 Mbps desktop switch The DS51072 5-Port Ethernet Network Switch enables up to 5 users to share files and devices (e.g. printers, scanners) over a LAN connection, by expanding an existing network's capacity with additional ports. Compatible with both 10Base-T (10 Mbps) and 100Base-TX (100Mbps) networks, this Fast Ethernet switch can automatically detect the type of network (auto- negotiation) as well as the type of cable (auto MDIX) and configure itself, making for an easy to install, Plug-and-Play networking solution. Backed by a StarTech.com 2-year warranty and free lifetime technical support. The StarTech.com Advantage - This 5-port Ethernet switch automatically detects and configures for network speed, duplex and cable type on each port, for a Plug-and-Play installation and setup - The switch features easily-accessed top-mounted LED indicators, and can be wall-mounted or placed on a desktop - The network switch uses a simple, fanless design for quiet and energy-efficient operation
Condition: Refurbished
Free U.S. ground shipping
Typically 1–2 days handling, 3–7 days in transit.
Purchase orders accepted
Government, enterprise, data center and small business.
Buying 10+ units?
Get volume pricing and availability for DS51072.
