40AH0135US - Lenovo 135-Watts Pro Docking Stations for ThinkPad L480 / L580 / P52S / T480
- Enterprise-class, universal, mechanical side-docking station
- Supports ThinkPad RapidCharge
- Built for 2018 ThinkPad L Series, T Series, X Series, and X1 Series laptops
- Can charge mobile devices with 15W and 10.5W from USB-C port and USB3.0 always power-on port respectively
Was $211.65 · You save $31.45
Key specifications
See full specs ↓- Connectivity technology
- Docking
- USB 2.0 ports quantity
- 2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 3
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
- 1
- DisplayPorts quantity
- 2
- Combo headphone/mic port
- Yes
Product details
Lenovo 40AH0135US. Connectivity technology: Docking, Headphone connectivity: 3.5 mm. Ethernet LAN data rates: 10,100,1000 Mbit/s. Product colour: Black, Data transfer rate: 5 Gbit/s, Maximum digital resolution: 4096 x 2160 pixels. Compatible power plug types: US. Width: 159 mm, Depth: 378 mm, Height: 54.1 mm
Ports & interfaces
| Connectivity technology | Docking |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| DisplayPorts quantity | 2 |
| Combo headphone/mic port | Yes |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
Network
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Wake-on-LAN ready | Yes |
| 10G support | No |
Performance
| Card reader integrated | No |
| Data transfer rate | 5 Gbit/s |
| Maximum digital resolution | 4096 x 2160 pixels |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Product colour | Black |
| Brand compatibility | Lenovo |
| Compatibility | P52s, L580, L480, T580, P580p, T480s, T480, X1 Carbon Gen 6, X280 |
| Certification | AS/NZS S-DOC, BSMI, CB, CE, EAC, EU DOC, FCC, ICES, KCC, NOM, UL/cUL, Ukr SEPRO, VCCI |
Power
| Compatible power plug types | US |
Operational conditions
| Operating temperature (T-T) | 0 - 35 °C |
Weight & dimensions
| Width | 159 mm |
| Depth | 378 mm |
| Height | 54.1 mm |
| Weight | 765 g |
Packaging data
| Package width | 200 mm |
| Package depth | 422 mm |
| Package height | 86 mm |
| Package weight | 1.95 kg |
Packaging content
| Warranty card | Yes |
| Cables included | AC |
| AC adapter included | Yes |
| User guide | Yes |
Description
The ThinkPad Pro Docking Station is designed exclusively for 2018 and newer ThinkPad T, L, X, and X1 Series laptops to provide the best docking experience for large enterprise ThinkPad customers. The innovative side connector provides a slim, driver-free way to connect conveniently and securely to a range of USB accessories and external displays, while rapid charging support and a mirrored power button make it easy to undock and go. For IT Managers, the mechanical ThinkPad Pro Dock supports PXE book, wake on LAN, and MAC address pass-through for, simplifying asset management. Painstakingly designed after extensive feedback from ThinkPad customers, these new ThinkPad docking stations provide seamless connectivity through dual USB-C and ethernet ports. Transfer data at 5 Gbps via three USB 3.1 ports, and connect to dual UHD displays, too.
Condition: Refurbished
Free U.S. ground shipping
Typically 1–2 days handling, 3–7 days in transit.
Purchase orders accepted
Government, enterprise, data center and small business.
Buying 10+ units?
Get volume pricing and availability for 40AH0135US.
