809948-001 - HP Backplane Board Assembly with Front 24-Bay Small form Factor (SFF) Drive Cage for Apollo 4200 G9 Server
- Supports up to 24 x 2.5-inch SFF SAS/SATA hard drives.
- Provides hot-swap capability for drives, allowing replacement without server downtime.
- Integrated backplane board assembly for simplified installation.
- Designed for specific HP ProLiant server models requiring high drive density.
- Facilitates data transfer and power distribution to all connected drives.
- Robust construction for reliable operation in enterprise environments.
Was $244.26 · You save $36.34
Key specifications
See full specs ↓- Product Type
- Drive Cage Backplane Board Assembly
- Drive Bays
- 24 x 2.5-inch SFF
- Interface
- SAS/SATA
- Hot Swap Support
- Yes
- Compatibility
- Specific HP ProLiant Servers
Product details
This HP 809948-001 is a 24-bay Small Form Factor (SFF) drive cage backplane board assembly. It is designed to provide connectivity and power management for a large number of hard drives within a server chassis. This backplane is crucial for enabling hot-swappable drive configurations in compatible HP ProLiant servers.
Technical Information
| Product Type | Drive Cage Backplane Board Assembly |
| Drive Bays | 24 x 2.5-inch SFF |
| Interface | SAS/SATA |
Additional Specifications
| Hot Swap Support | Yes |
| Compatibility | Specific HP ProLiant Servers |
Description
The HP 809948-001 backplane board assembly is engineered to maximize storage density within compatible HP ProLiant server platforms. It serves as the central hub for connecting up to twenty-four 2.5-inch Small Form Factor (SFF) SAS or SATA hard drives. This design is ideal for environments that require extensive local storage, such as high-performance computing, large databases, or virtualization hosts. Featuring integrated hot-swap capabilities, this backplane allows administrators to add or replace drives without interrupting server operations. This feature is critical for maintaining high availability and minimizing downtime in mission-critical applications. The assembly includes the necessary circuitry for power delivery and data signaling to each drive bay, ensuring reliable performance and data integrity. Constructed with enterprise-grade components, the 809948-001 is built for durability and sustained operation under demanding workloads. Its design simplifies the installation process by integrating the drive cage and backplane into a single unit, reducing cabling complexity and potential points of failure. This component is essential for servers configured for maximum storage capacity and performance.
