Dell 210-AFSZ S3124P 24-Ports + 2x SFP+ L3 Network Switch
- Managed
- Configuring Location Settings (CLI)
- Basic switching RJ-45 Ethernet ports quantity: 24 Console port: RJ-45
- 10G support
- MAC address table: 56000 entries Switching capacity: 212 Gbit/s
- 1U Rack mounting Stackable
- Power supply included Power over Ethernet (PoE)
Was $1,423.18 · You save $213.18
Key specifications
See full specs ↓- Switch type
- Managed
- Configuring Location Settings (CLI)
- Yes
- Basic switching RJ-45 Ethernet ports quantity
- 24
- Basic switching RJ-45 Ethernet ports type
- Gigabit Ethernet (10/100/1000)
- Combo SFP ports quantity
- 2
- SFP+ module slots quantity
- 1
Documents
Product details
DELL S-Series S3124P. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24, USB 2.0 ports quantity: 1, Console port: RJ-45. Full duplex. MAC address table: 56000 entries, Switching capacity: 212 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE.... Power over Ethernet (PoE). Rack mounting, Form factor: 1U
Management features
| Switch type | Managed |
| Configuring Location Settings (CLI) | Yes |
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Combo SFP ports quantity | 2 |
| SFP+ module slots quantity | 1 |
| Console port | RJ-45 |
| Number of mini-SAS stacking ports | 2 |
| Mini-SAS stacking port data rate (max) | 21 Gbit/s |
| USB 2.0 ports quantity | 1 |
Network
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ba, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | Yes |
| Port mirroring | Yes |
| Full duplex | Yes |
| Flow control support | Yes |
| Auto MDI/MDI-X | Yes |
| Auto-sensing | Yes |
| Auto-negotiation | Yes |
| VLAN support | Yes |
| Virtual LAN features | Tagged VLAN |
| Number of VLANs | 2 |
Data transmission
| Switching capacity | 212 Gbit/s |
| Forwarding rate | 158 Mpps |
| MAC address table | 56000 entries |
| Store-and-forward | Yes |
| Packet buffer memory | 4 MB |
Security
| SSH/SSL support | Yes |
| Authentication type | RADIUS |
| Supports separation | PoE+ |
Multicast features
| Multicast support | Yes |
Protocols
| Supported network protocols | IPv4 e IPv6 Roteamente Estático, RIP, OSPFv2 ,OSPFv3, BGP e IS-IS |
Design
| Rack mounting | Yes |
| Stackable | Yes |
| Form factor | 1U |
| Product colour | Black |
Performance
| Memory type | DDR3-SDRAM |
| Internal memory | 2048 MB |
| Flash memory | 1024 MB |
| Compatible operating systems | OS 9 |
Power
| Power supply included | Yes |
| AC input voltage | 100 - 250 V |
| AC input frequency | 50 - 60 Hz |
| Output voltage | 250 V |
| Power consumption (max) | 53.5 W |
| Power cable length | 2 m |
| Power cable connector 1 | NBR14136 |
| Power cable connector 2 | C13 coupler |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 24 |
| Power over Ethernet (PoE) power per port | 30.8 W |
Other features
| Cable length | 2 m |
Operational conditions
| Operating temperature (T-T) | 0 - 45 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Heat dissipation | 4391.42 BTU/h |
Weight & dimensions
| Width | 434 mm |
| Depth | 407 mm |
| Height | 43.5 mm |
| Weight | 6.6 kg |
Description
The Dell Networking S3124P (210-AFSZ) is a high-performance Layer 3 switch designed to meet the demands of modern enterprise networks. It features 24 Gigabit Ethernet RJ45 ports for connecting end devices and servers, along with two 10 Gigabit Ethernet SFP+ ports for high-speed uplinks to core networks or other switches. This configuration provides a robust foundation for campus networks, branch offices, and data center aggregation layers. With its Layer 3 routing capabilities, the S3124P enables efficient traffic management and network segmentation, allowing for better control and performance. It boasts a high switching capacity of 560 Gbps and a forwarding rate of 417 Mpps, ensuring that network traffic flows smoothly even under heavy loads. The switch supports advanced features such as static and dynamic routing protocols, Quality of Service (QoS), and comprehensive security options, including Access Control Lists (ACLs) and 802.1X authentication. The Dell S3124P is designed for ease of deployment and management, offering multiple management interfaces including a web-based GUI, Command Line Interface (CLI), and SNMP. It also supports stacking, allowing multiple switches to be managed as a single logical unit, which simplifies administration and increases port density. This switch is an excellent choice for organizations seeking a reliable, scalable, and feature-rich networking solution.
