APC AP8981 11000-Watts 230V 21 IEC 60320 C13 Power Distribution Unit
- Capacity: 11000 Watts.
- Voltage: 230V.
- Outlets: 21 x IEC 60320 C13 outlets.
- Network Interface: Built-in network management for remote monitoring and control.
- Input Plug Type: Hardwired or specific connector (details not in title).
- Rackmount design for easy installation.
- Supports remote outlet control for power cycling.
Was $310.65 · You save $46.30
Key specifications
See full specs ↓- PDU types
- Metered, Switched
- Rack capacity
- 0U
- Product colour
- Black
- AC outlets quantity
- 24 AC outlet(s)
- Input connection type
- IEC 309 16A 3P+N+PE, IEC 309 20A 3P+N+E
- Output connections
- (21) IEC 320 C13, (3) IEC 320 C19
Documents
Product details
APC AP8981. PDU types: Metered, Switched, Rack capacity: 0U, Product colour: Black. AC outlets quantity: 24 AC outlet(s), Input connection type: IEC 309 16A 3P+N+PE, IEC 309 20A 3P+N+E, Output connections: (21) IEC 320 C13, (3) IEC 320 C19. Cable length: 1.83 m. Nominal input voltage: 400 V, AC input frequency: 50 - 60 Hz, Maximum input current per phase: 20 A. Width: 56 mm, Depth: 46 mm, Height: 1791 mm
Design
| PDU types | Metered, Switched |
| Rack capacity | 0U |
| Product colour | Black |
Ports & interfaces
| AC outlets quantity | 24 AC outlet(s) |
| Input connection type | IEC 309 16A 3P+N+PE, IEC 309 20A 3P+N+E |
| Output connections | (21) IEC 320 C13, (3) IEC 320 C19 |
Features
| Cable length | 1.83 m |
Power
| Nominal input voltage | 400 V |
| AC input frequency | 50 - 60 Hz |
| Maximum input current per phase | 20 A |
| Maximum total current draw per phase | 20 A |
Operational conditions
| Operating temperature (T-T) | -25 - 65 °C |
| Storage temperature (T-T) | -5 - 45 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Width | 56 mm |
| Depth | 46 mm |
| Height | 1791 mm |
| Weight | 7 kg |
Packaging data
| Package weight | 8.95 kg |
| Package width | 165 mm |
| Package depth | 114 mm |
| Package height | 2002 mm |
Description
APC Switched Rack PDU , Input: 400V 3PH , Input Connections: IEC 309 16A 3P+N+PE, IEC 309 20A 3P+N+E , Cord Length: 6 feet ( 1.83 meters ) , Output: 208V, 230V , Output Connections: IEC 320 C13,IEC 320 C19. Includes: Installation guide, Rack Mounting brackets, Safety guide, Sample locking IEC power cord, Serial configuration cable.
