C7796D - HP DesignJet 110 Plus Color InkJet Printer
- 1200 x 600 DPI Colour
- A1 (594 x 841 mm) Printing colours: Black, Cyan, Magenta, Yellow
- USB port
C7796D isn't on our shelf today — we source it to order. Request a quote and we'll confirm price and lead time within one business day.
Key specifications
See full specs ↓- Print head nozzles
- 304
- Colour printing technology
- HP Color Layering technology
- Colour
- Yes
- Maximum resolution
- 1200 x 600 DPI
- Printing colours
- Black, Cyan, Magenta, Yellow
- Maximum duty cycle
- 7000 pages per month
Product details
HP Designjet 110plus Printer. Maximum resolution: 1200 x 600 DPI, Printing colours: Black, Cyan, Magenta, Yellow, Maximum duty cycle: 7000 pages per month. Total input capacity: 150 sheets, Total output capacity: 50 sheets, Maximum input capacity: 100 sheets. Maximum print size: A1 (594 x 841 mm), Media types supported: Paper (plain, inkjet, coated, heavyweight, semi-gloss, glossy, proofing, photo, brochure/flyer,..., ISO A-series sizes (A0...A9): A1, A2, A3, A4. USB connector: USB Type-A. Internal memory: 64 MB, Built-in processor: Impala 2 ASIC, Processor frequency: 16 MHz
Printing
| Print head nozzles | 304 |
| Colour printing technology | HP Color Layering technology |
| Colour | Yes |
| Maximum resolution | 1200 x 600 DPI |
| Printing colours | Black, Cyan, Magenta, Yellow |
| Maximum duty cycle | 7000 pages per month |
| Print head | 4 (1 each cyan, magenta, yellow, black) |
| Print time colour line drawing (draft, A1) | Up to 1.5 min/page |
Input & output capacity
| Total number of input trays | 1 |
| Total input capacity | 150 sheets |
| Total output capacity | 50 sheets |
| Maximum input capacity | 100 sheets |
| Maximum output capacity | 50 sheets |
Paper handling
| Paper handling | Sheetfed (automatic input tray for 150 sheets up to A2+, front manual single-sheet feed, rear manual path for thick media), optional roll-feed with automatic cutter |
| Duplex print options | None (not supported) |
| Maximum length of sheet media | 1625 mm |
| Standard media sizes | A1, A1+, A2, A3, A4, B2, B3, B4, envelopes |
| Media types supported | Paper (plain, inkjet, coated, heavyweight, semi-gloss, glossy, proofing, photo, brochure/flyer, natural tracing), translucent bond, A4 transparencies |
| Custom media sizes | Tray 1: 76 x 142 to 457 x 610 mm; manual sheet feed: 110 x 205 to 625 x 1625 mm; rear path: 110 x 205 to 625 x 1625 mm; roll feed: up to 609 mm |
| Maximum print size | A1 (594 x 841 mm) |
| ISO A-series sizes (A0...A9) | A1, A2, A3, A4 |
| ISO B-series sizes (B0...B9) | B2 |
| Maximum roll length | 45.7 m |
| Maximum roll diameter | 10 cm |
| Print margin cut-sheet | 5 x 12 x 5 x 5 |
| Print margin roll | 5 mm |
| Media weights by paper path | Tray 1: 65 to 150 g/m2; manual single-sheet feed: 65 to 150 g/m2; rear path: up to 300 g/m2 |
| Maximum media width | 625 mm through front manual feed path |
| Roll top margin | 5 mm |
| Recommended media weight | Tray 1: 65 - 150; manual single-sheet feed: 65 - 210; rear path: up - 300; roll feed: 65 - 150 |
| Media handling | Input tray, manual single-sheet feed, rear path (minimum A2, maximum A1 oversize), roll feed through rear path |
| Maximum paper trays | 1 |
| Paper handling optional/input | Optional automatic roll feed, spindle |
| Paper handling standard/input | 100-sheet A2-size input tray, manual single-sheet feed, single-sheet rear path for thick media, optional automatic roll feed |
| Media sizes supported (imperial) | Letter, legal, tabloid, C, D, D+, envelopes |
| Media thickness (by paper path) | Tray 1: up to 8 mil; envelopes: up to 15 mil; front path: up to 8 mil; rear path: up to 15 mil |
| Non-printable area roll media (imperial) | 0.2 x 0.2 x 0.2 x 0.2 in |
| Recommended media weight (imperial) | 17 to 56 lb |
Ports & interfaces
| Ethernet LAN | No |
| USB port | Yes |
| USB connector | USB Type-A |
| USB 2.0 ports quantity | 1 |
| Parallel ports quantity | 1 |
Performance
| Internal memory | 64 MB |
| Built-in processor | Impala 2 ASIC |
| Processor frequency | 16 MHz |
| Drive device, buffer size | 32 MB |
Power
| Power requirements | Input voltage 100 to 240 VAC (± 10%) auto ranging, 50/60 Hz (± 3Hz), 2 amp maximum |
Operational conditions
| Recommended operating temperature range (T-T) | 15 - 30 °C |
| Operating temperature (T-T) | 15 - 30 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -20 - 55 °C |
| Operating temperature (T-T) | 59 - 86 °F |
| Storage relative humidity (H-H) | 20 - 80% |
System requirements
| Mac compatibility | Yes |
| Browser supported | Microsoft Internet Explorer 5.5 and above, Netscape 6.1 and above |
| Compatible operating systems | Microsoft Windows XP Home, XP Professional, Windows Vista; Mac OS 9.2; Mac OS 10.2; Mac OS 10.3, 10.4 and 10.5 |
Sustainability
| Sustainability certificates | ENERGY STAR |
Weight & dimensions
| Maximum dimensions (W x D x H) | 1042 x 1020 x 220 mm |
| Dimensions (WxDxH) | 1042 x 414 x 220 mm |
| Weight | 22 kg |
| Pallet dimensions (W x D x H) | 1200 x 110 x 2098 mm |
| Pallet dimensions (W x D x H) (imperial) | 1198.9 x 1099.8 x 2098 mm (47.2 x 43.3 x 82.6") |
| Product dimensions when open (LxWxD) | 104.1 cm (41") |
| Size (imperial) | 61 cm (24") |
| Weight (imperial) | 48.5 lb |
Packaging data
| Package weight | 34 kg |
| Package dimensions (WxDxH) | 1192 x 545 x 493 mm |
| Package dimensions (W x D x H) | 1191.3 x 546.1 x 492.8 mm (46.9 x 21.5 x 19.4") |
| Package weight (imperial) | 34 kg (75 lbs) |
| Bundled software | HP Designjet System Maintenance |
Other features
| Minimum system requirements for Macintosh | iMac G3, G4, G5 dual processor; iBook; PowerBook; eMac |
| Line accuracy | +/- 0.2 % |
| Minimum line width | 0.04 mm |
| Compatible ink types, supplies | Black: HP pigment ink; cyan, magenta, yellow: HP dye-based ink |
| Acoustic power emissions | 6.2 B(A) (active, printing), 5.4 B(A) (standby) |
| Print quality (colour, best quality) | 1200 DPI |
| Minimum system requirements | Pentium III (733 MHz), 128 MB RAM, 400 MB available hard disk space Pentium 4 (1 GHz), 256 MB RAM, 2 GB available hard disk space G3 dual processor, 1 GB RAM, 1 GB available hard disk space |
| Embedded web server | Yes |
| Electromagnetic compatibility | Compliant with requirements for Class B ITE products (Class A when connected to LAN cables), EU (EMC Directive), US (FCC rules), Canada (DOC), Australia (ACA), New Zealand (MoC), China (CCC), Japan (VCCI), Class A for Korea (MIC), Taiwan (BSMI) |
Description
Expand your in-house colour printing capabilities on a range of common and large-format media sizes – all at a low purchase price. The versatile, multi-format HP Designjet 110plus produces professional results for all your document needs. Enjoy versatile colour printing on a wide range of media types and sizes up to A1+. • Expand your in-house colour printing capabilities to include a wide range of media sizes and types with this versatile multi-format colour printer. The standard tray handles media up to A2+ and two manual-feed paths handle larger sizes (up to A1+). Get the most from your budget with this multi-format printer that is cost-effective to own and use. • Meet your multi-format colour printing needs without overstretching your budget. The HP Designjet 110plus offers an attractively low purchase price and a low cost of operation making it both budget friendly and cost-effective. Get high-quality results and experience the professional performance you expect from an HP printer. • Get high-quality results and reliable performance. The HP Designjet 110plus uses 1200 dpi and HP Color Layering Technology for detailed image quality and vibrant colour. Black pigmented HP ink1 ensures lasting results for archiving CAD drawings. 1 With the HP 10 Black Pigmented Ink Cartridge and Printhead (in accordance with ISO 11798)
