APC SMT750RMI2UC 750VA 500-W 230V 4 IEC 320 C13/ 2 IEC Jumpers UPS

APC SMT750RMI2UC 750VA 500-W 230V 4 IEC 320 C13/ 2 IEC Jumpers UPS

SKU SMT750RMI2UC
APCShop all APC parts (559) ›
  • Line-Interactive
  • 0.75 kVA 500 W
  • 4 AC outlet(s)
  • Sealed Lead Acid (VRLA)
  • Rackmount Black
In Stock
$1,086.05

Was $1,277.35 · You save $191.30

Free U.S. ground shippingArrives Wed, Nov 25 – Wed, Dec 2Faster options available at checkout

Key specifications

See full specs ↓
UPS topology
Line-Interactive
Output power capacity
0.75 kVA
Output power
500 W
Waveform
Pure sine
Input operation voltage (min)
151 V
Input operation voltage (max)
302 V

Product details

APC Smart-UPS SMT750RMI2UC - 4x C13, USB, Rackmount 2U, SmartConnect, 750VA. UPS topology: Line-Interactive, Output power capacity: 0.75 kVA, Output power: 500 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 4 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 168 VAh, Typical backup time at full load: 5.5 min. Form factor: Rackmount, Product colour: Black, Rack capacity: 2U. Compliance certificates: RoHS, Certification: CE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, TUV, UL 1778, VDE, REACH, PEP, EOLI

Specifications

UPS topology
Line-Interactive
Output power capacity
0.75 kVA
Output power
500 W
Waveform
Pure sine
Input operation voltage (min)
151 V
Input operation voltage (max)
302 V
Input frequency
50/60 Hz
Output operation voltage (min)
220 V
Output operation voltage (max)
240 V
Automatic Voltage Regulation (AVR)
Yes
Surge energy rating
459 J
Hold time (max)
2 ms
Efficiency
97.7%
Noise level
42 dB
Surge protection
Yes
Audible alarm(s)
Yes
Auto-restart
Yes
AC outlet types
C13 coupler
Power plug
C14 coupler
AC outlets quantity
4 AC outlet(s)
Number of output IEC jumpers
2
USB port
Yes
Serial interface
Yes
Serial interface type
RJ-45
SmartSlot
Yes
SmartConnect port
Yes
Battery technology
Sealed Lead Acid (VRLA)
Battery capacity
168 VAh
Typical backup time at full load
5.5 min
Typical backup time at half load
16 min
Battery life (max)
5 year(s)
Battery recharge time
3 h
Hot-swap battery
Yes
Automatic battery test
Yes
Cold start
Yes
Form factor
Rackmount
Rack capacity
2U
Product colour
Black
LED indicators
Battery replacement
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-15 - 45 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3000 m
Non-operating altitude
0 - 15000 m
Compliance certificates
RoHS
Certification
CE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, TUV, UL 1778, VDE, REACH, PEP, EOLI
Rack mount kit
Yes
Cables included
RS-232, USB cable
Management card included
No
Quick installation guide
Yes
Sustainability certificates
Green Premium
Width
432 mm
Depth
406 mm
Height
89 mm
Software CD
Yes
Package width
546 mm
Package depth
584 mm
Package height
241 mm
Package weight
21.2 kg
Products per pallet
16 pc(s)
Harmonized System (HS) code
85078000
Total carbon footprint (kg of CO2e)
821.3

Description

Stay always online and prevent data loss As soon as the power fails, an APC Smart-UPS immediately supplies emergency power to all connected equipment. Because an APC UPS does this automatically, you prevent unwanted failure of, for example, a PC, server or switch. With the free APC PowerChute software, you can even have critical IT hardware shut down automatically and in a controlled manner when the battery of the UPS is almost empty. This prevents data loss, downtime and physical damage to hardware. Safety In addition, a Smart-UPS protects connected devices against peak voltage caused by lightning, among other things. This APC emergency power supply is ideally suited for (small) business use. Battery life You can easily read the expected battery life in the runtime graph, which you can find between the product images. This makes it easy to see how long the UPS will supply emergency power at a certain load. SmartConnect Out-of-box remote UPS monitoring, free during a 6-month trial period. Using the SmartConnect Ethernet port, you can easily connect the Smart-UPS to your network and monitor it remotely via the secure APC SmartConnect cloud-based web portal*. In addition, the UPS can always be monitored via this port via EcoStruxure IT Expert (SFTWES1-DIGI). * Extend access to SmartConnect via the following licenses: 1 year Standard Plan: ERWPMON1-1Y-DIGI 3 years Standard Plan: ERWPMON1-3Y-DIGI 1 year Advanced Plan: ERWPLUS1-1Y-DIGI 3 years Advanced Plan: ERWPLUS1-3Y-DIGI PowerChute By connecting the UPS to a maximum of one server via a USB cable, it can automatically provide it with a shutdown signal during a prolonged power failure and thus still prevent a hard shutdown. This exact moment can be set via the free APC PowerChute Serial Edition software. Network Management Card If you connect the UPS via the optional APC Network Management Card (AP9640/AP9641) directly to your network, it can be easily managed remotely via SNMP or our remote management software Ecostruxure IT Expert (SFTWES1-DIGI). You can also automatically send a shutdown signal via the network to multiple physical and/or virtual servers. By means of the APC PowerChute Network Shutdown Software belonging to the network card, it is even possible to differentiate the shutdown moment and the order in which this happens. Ease of use By means of physical buttons and an LCD screen, it is possible to set and read out the basic functionalities. Thanks to the supplied 4-post rail kit, you can easily mount the UPS in a rack. Extend the lifespan The internal battery cartridge (APCRBC123) can be replaced easily, safely and independently by the user. This without having to switch off the APC SMT750RMI2UC or connected equipment. This way you can easily and cheaply extend the lifespan of the APC Smart-UPS and your equipment always stays online. Warranty extension The factory warranty of the SMT750RMI2UC is 3 years, with the exception of the battery cartridge, which has a factory warranty of 2 years. Both are extended by 3 years to 6 and 5 years respectively with the APC service pack (WBEXTWAR3YR-SP-02). Switched Outlet Groups: Remote reboot and phased start-up Thanks to the Switched Outlet Groups it is possible to configure a phased/delayed power-on per UPS outlet group. This reduces the peak load on the UPS and brings it closer to the constant load, which can limit oversizing of the UPS. It is also possible to reset a group of multiple UPS outputs and the equipment connected to them. If SmartConnect Advanced (ERWPLUS1-1Y-DIGI), a UPS with SmartConnect port + Ecostruxure IT Expert (SFTWES1-DIGI) or a network card (ap9640) in combination with Ecostruxure IT Expert (SFTWES1-DIGI) are used, this can even be done remotely. This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 750VA line interactive 2U rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with IEC 320 C14 input, 4x IEC 320 C13 outlets, and 2x IEC jumper cables. It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMT UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. It is compatible with a dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications.
