APC AP8953 230V 32A 21 IEC 60320 C13 Rackmount Power Distribution Unit

SKU AP8953

Brand APC

21 x IEC C13 outlets
230V input voltage
32A input current
Rackmount form factor
Remote on/off switching
Power monitoring capabilities
High power capacity
Network manageable

In Stock

$396.02

Was $465.55 · You save $69.53

Key specifications

See full specs ↓

PDU types: Metered, Switched
Type: Single-phase
Rack capacity: 0U
Mounting: Vertical
Product colour: Black
AC outlets quantity: 24 AC outlet(s)

Documents

Brochure APC AP8953Brochure · PDF

Product details

APC Rack PDU 2G, Switched, 32A, 230V, (21) C13 & (3) C19 (BEING DISCONTINUED, SEE APDU9953). PDU types: Metered, Switched, Rack capacity: 0U, Type: Single-phase. AC outlets quantity: 24 AC outlet(s), AC outlet types: C13 coupler, C19 coupler, Power plug: IEC309. Cable length: 3.05 m. AC input frequency: 50 - 60 Hz, Maximum input current per phase: 32 A, Maximum total current draw per phase: 32 A. Width: 56 mm, Depth: 46 mm, Height: 1829 mm

Design

PDU types	Metered, Switched
Type	Single-phase
Rack capacity	0U
Mounting	Vertical
Product colour	Black

Ports & interfaces

AC outlets quantity	24 AC outlet(s)
Power plug	IEC309
AC outlet types	C13 coupler, C19 coupler
Input connection type	IEC 309 32A 2P+E
Output connections	(21) IEC 320 C13, (3) IEC 320 C19

Features

Cable length

3.05 m

Power

AC input frequency	50 - 60 Hz
Maximum input current per phase	32 A
Maximum total current draw per phase	32 A

Operational conditions

Operating temperature (T-T)	-25 - 65 °C
Storage temperature (T-T)	-5 - 45 °C
Operating relative humidity (H-H)	5 - 95%
Storage relative humidity (H-H)	5 - 95%

Weight & dimensions

Width	56 mm
Depth	46 mm
Height	1829 mm
Weight	7.59 kg

Packaging data

Package weight	9.95 kg
Package width	165 mm
Package depth	124 mm
Package height	2040 mm

Description

APC Switched Rack Power Distribution Units (PDUs) enable advanced, user-customizable power control and active monitoring. The output and input connections are (21) C13 & (3) C19, and the cable length is 3m. Remote outlet level controls allow power on/off functionality for power recycling to remotely reboot equipment and restrict unauthorized use of individual outlets. Power sequencing delays allow users to define the order in which to power up or down attached equipment. Avoid circuit overload during power recovery and extend uptime of critical equipment by prioritizing the load shedding. Current metering provides real-time remote monitoring of connected loads. Switched Rack PDUs include real power monitoring, a temperature/humidity sensor port, locking IEC receptacles, and low profile circuit breakers. User-defined alarms warn of potential circuit overloads before critical IT failures occur. Users can access, configure, and control Switched Rack PDUs through secure Web, SNMP, or Telnet Interfaces and is complimented by APC Centralized Management platforms using InfraStruxure Central, Capacity Manager and Change Manager.

Condition: Refurbished
