AP9630 - APC UPS Network Management Card 2 for Smart-UPS 1000

AP9630 - APC UPS Network Management Card 2 for Smart-UPS 1000

SKU AP9630
APCShop all APC parts (559) ›
  • Enables remote monitoring and management of APC Smart-UPS.
  • Provides network access to UPS status, events, and configuration.
  • Supports SNMP, HTTP, Telnet, and SSH protocols for versatile management.
  • Offers environmental monitoring capabilities with optional sensors.
  • Features firmware update capability for future enhancements.
  • Includes a built-in Web interface for easy access.
  • Compatible with a wide range of APC Smart-UPS models.
In Stock
$162.38

Was $190.68 · You save $28.30

Free U.S. ground shippingArrives Mon, Nov 23 – Mon, Nov 30Faster options available at checkout

Key specifications

See full specs ↓
Host interface
SmartSlot
Ethernet LAN (RJ-45) ports
1
Ethernet interface type
Fast Ethernet
Ethernet LAN data rates
10,100 Mbit/s
Cabling technology
10/100BaseT(X)
Security algorithms
SNMP

Product details

APC 10/100BASE-T network management card 2. Host interface: SmartSlot

Specifications

Host interface
SmartSlot
Ethernet LAN (RJ-45) ports
1
Ethernet interface type
Fast Ethernet
Ethernet LAN data rates
10,100 Mbit/s
Cabling technology
10/100BaseT(X)
Security algorithms
SNMP
Supported network protocols
HTTPS, HTTP, Telnet, SMTP, TCP/IP
Certification
FCC part 15 class A GOST EN 55022 class A ICES-003 AS/NZS 3548 (C-Tick) class A VCCI class A EN 55024
Operating temperature (T-T)
0 - 45 °C
Storage temperature (T-T)
-5 - 45 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%
Width
121 mm
Depth
114 mm
Height
38 mm
Package width
235 mm
Package depth
159 mm
Package height
51 mm
Package weight
340 g
Manual
Yes
Compliance certificates
RoHS
Harmonized System (HS) code
85176990
Product type
Network management card

Description

APC UPS Network Management Cards allow for secure monitoring and control of an individual APC UPS via web browser, command line interface, or SNMP. The configurable notification features keep you informed of problems as they occur. For protected servers, the included PowerChuteTM Network Shutdown software provides graceful, unattended shutdown in the event of an extended power outage, always keeping business information safe. Protection Password security User-selectable password protection prevents unauthorized access, authorized against LDAP and Active Directory servers. PowerChute Network Shutdown Reliable network-based shutdown of multiple servers Radius support Use an existing radius server to securely authenticate, authorize, and account for your APC device. Multi-tier user access Supports up to four access levels - Administrator, Device User, Read-Only User and Network-only User - with user name and password requirements. Manageability Notification Be notified of problems to ensure crucial situations are dealt with in a timely manner. Data logging Identify problematic trends before they escalate or export the data log for analysis. Scheduling Customize shut down and reboot of connected equipment and UPSs. Integrates with StruxureWare Data Center Expert An IT-ready, scalable access monitoring system that collects, organizes, and distributes critical alerts, surveillance video and key information, providing a unified view of complex physical infrastructure environments from anywhere on the network Event logging Pinpoint the timing and sequence of events leading up to an incident with the event log. Enterprise management system compatible Make device information available to your preferred enterprise management system by forwarding SNMP traps (events) across SNMPv1, SNMPv2 and SNMPv3 using the PowerNet MIB
